HCW1240

Functional Overview

The 12 superb RGBW LEDs in the HTC1240 require a combined 40W of power and are distributed among circular pixels. A narrow beam wash and a large angle wash are produced by linearly altering the beam angle from 3.5 to 45 degrees. Its dramatic and dazzling LED moving head light makes it practical in a range of circumstances.

Tech Specs

Optics:
Light Sources: 12 x 40W 4in1 RGBW LED
Beam Angle: 3.5° ~ 45°
Power Consumption: 400W
Power Voltage: AC 100-240V, 50/60Hz

Control:
DMX Channel: 21/25/33/81 Channel
Control Modes: DMX512/Master-Slave/Auto Run/Music

Pan/Tilt:
Pan/Tilt: 540°or 360° in optional / 270°
Pan/Tilt Resolution: 8/16 bit

Specification:
Dimension: 324x240x377mm
Net Weight: 9.5Kgs

Construction:
Display: 1.8 TFT colorful Display
Data In/Out socket: 3-pin & 5-pin XLR sockets
Power Socket: Power Con in/out
Protection Rating: 1P20

Features:
LED single control, con display arrows, numbers, letters and patterns
High-efficiency optical system
Outstanding color macro effect
Dimmer: 0~100% smooth dimming
Variable strobe effects
Fast, quiet operation and flicker-free

Downloads

Dimensions

Dimensions Diagram
