HCW640
Functional Overview
Retro Triangle LED Each light's luminous area is divided into 16 smaller equilateral triangles, giving the luminary its equilateral triangle shape. Lights can be set in an array of one or more. Each of 16 four-color LEDs can be independently controlled. The infinite modeling incorporates running geometric graphics, line drawing, running lights, dimming, and 4-color LED color rendering.
Technical Specifications
Light Sources: 6x40W 4IN1 RGBW LED
Beam Angle: 3.5°-45°
Power Consumption: 220W
Power Voltage: AC 100-240V, 50/60Hz
DMX Channel: 21/24/32/56 Channel
Control Modes: DMX512/mater-Slave/Auto Run/Music/RDM
Pan/Tilt: 540°/ 270° Pan/Tilt Resolution: 8/16 bit
Display: 180°reversible LCD colorful Display
Data In/Out socket: 3-pin XLR sockets
Power Socket: Powercon in/out
Protection Rating: IP20
Motorized liner zoom system, zoom range: 3.5°~45° pixels control
Outstanding color macro effect
Dimmer: 0~100% smooth dimming
Variable strobe effects
Fast, quiet operation and flicker free
Dimension: 258mm×178mm×334 mm
Net Weight: 5.6 Kgs
Carton package 1in1 size: 31*23*42cm Gross weight：6.4Kgs
Carton package 4in1 size: 64*48*43.5cm Gross weight：27Kgs
Beam Angle: 3.5°-45°
Power Consumption: 220W
Power Voltage: AC 100-240V, 50/60Hz
DMX Channel: 21/24/32/56 Channel
Control Modes: DMX512/mater-Slave/Auto Run/Music/RDM
Pan/Tilt: 540°/ 270° Pan/Tilt Resolution: 8/16 bit
Display: 180°reversible LCD colorful Display
Data In/Out socket: 3-pin XLR sockets
Power Socket: Powercon in/out
Protection Rating: IP20
Motorized liner zoom system, zoom range: 3.5°~45° pixels control
Outstanding color macro effect
Dimmer: 0~100% smooth dimming
Variable strobe effects
Fast, quiet operation and flicker free
Dimension: 258mm×178mm×334 mm
Net Weight: 5.6 Kgs
Carton package 1in1 size: 31*23*42cm Gross weight：6.4Kgs
Carton package 4in1 size: 64*48*43.5cm Gross weight：27Kgs
