TB1440IP

Functional Overview

The TB1440IP is a fantastic LED Bar light for usage indoors and outdoors with IP65 and 14 pcs of 40W 4in1 RGBW LEDs. It offers a variety of configurations such as 16x30W LED 4 in 1, 18x15W 4in1, 18x20W 6in1. Each LED has independent control. Its total of 72 DMX Channels makes for amazing color effects. Its 400Hz refresh rate makes it appropriate for TV studio use.

Tech Specs

Input voltage: AC 100V/120V/200V/220V /230V/240V 50/60Hz
Power: 600W @220V
LED light source: 14 PCS 40W RGBW
Working lifetime: 50000h
Dimmer: 0-100% linear dimming
Strobe: Electric strobe-0.3-20pcs/sec Max 20 Hz
Control mode: International standard DMX 512 signal: 3 Pin (5 Pin) DMX512 interface RDM, Wireless: 2.4 GHz W-DMX™ (optional)
Channel modes: 3 channel modes, Master-slave, Stand-alone mode, Self-test mode
Other functions: Adjustable horizontal and vertical speed, Display fixture using time, Display software version number, Modular structure for easy maintenance, Speed-regulating radiator
Shell and protection level: High-strength casting aluminum alloy, IP65 black shell, white optional
Working temperature: -20°C-40°C
Weight: 9.2 Kg

Downloads

Dimensions

Dimensions Diagram

Optionals

Case

Case

Clamps

Clamps

Cables

Cables
